Sunda Baffle

Installing Sunda Baffle is simple, and you won’t necessarily need a specialist installer. Each baffle comes with 2-3 spiral hooks, depending on its size, which should be placed approximately 150mm to 200mm from the baffle’s edge and securely fastened. Once in place, the adjustable wires can be attached to the soffit using the Top Hat fixings included.

Determining the optimal quantity of Sunda Baffles isn’t an exact science. Broadly, increased surface coverage leads to greater sound absorption and reduced echo. As a general guideline, aiming to cover approximately 30% to 50% of the ceiling area typically results in effective sound absorption.

You can use our reverberation calculator as a helpful tool in this process.

Sunda Baffle is made using a dense glass wool core of which offers high levels of sound absorption and is also a sustainable material, the face of Sunda Baffle is a high-quality fabric to give a premium finish and offers a wide variety of colour choice.

Each Sunda Baffle order will come with the correct amount of hanging kits. These kits consist of a Top Hat fixing (bullet which screws into the ceiling), 2m Adjustable Wire, Clip (this is to feed the wire through) and a Spiral Hook (anchors into the baffle). The only fixings you will need in addition to these hanging kits are the screws to attach the Top Hat fixing to the soffit. We do not supply these screws as the appropriate screws will dependant on your soffit structure i.e. Plasterboard, concrete, timber which your local DIY store will be able to recommend.

We use Camira Lucia as standard, but we can manufacture using alternative fabrics on request.

Yes, although we have a standard range of the most popular sizes it is possible to have a customised shape or size of Sunda Baffle to suit your requirements.

However, there are some limitations in these shapes and max sizes that are possible to manufacture due to weight and panel size. Please get in touch to discuss what’s possible.

When installing Sunda Baffle, you should consider the mounting surface. The right surface should ensure a secure, long-lasting installation.

Suitable surfaces include:

• Drywall: Attach baffles using suitable screws, ensuring the drywall is in good condition.
• Concrete: Use appropriate fasteners like concrete screws or anchors to securely attach baffles.
• Plywood: Mount baffles directly or install plywood as a substrate over other surfaces.
• Metal Studs: In commercial/industrial spaces, attach baffles directly to metal studs using suitable screws.
• Exposed Beams: In open spaces, use clamps or brackets designed for beam mounting. Ensure the surface is clean, dry, and capable of supporting the baffle’s weight.
• Suspended Ceiling: Fix through the ceiling tile and then into a timber pattress for support or use lighting/signage clips to suspend from the ceiling grid.

You can follow our installation guide for a full step by step installation found on our data sheet on this page.

The only fixings you will need in addition to the supplied hanging kits are the screws to attach the Top Hat fixing to the soffit. We do not supply these screws as the appropriate screws will dependant on your soffit structure ie. Plasterboard, concrete, timber which your local DIY store will be able to recommend.

Sunda Baffle comes with a one-year manufacturer’s warranty, providing coverage for any defects in materials or workmanship. This warranty is to ensure peace of mind for our customers, guaranteeing reliable performance and quality assurance.

Yes, Sunda Baffle core board has been tested and offers EN 13501-1:2018 A2-s1, d0 and Class O fire rating to BS476: Part 6. Fabric facing complies with EN1350-1 Class B, s1, d0.

Sunda Baffle effectively absorbs direct sound and reflections from ceilings and upper wall sections. While it doesn’t address noise transfer between rooms, it noticeably diminishes noise within an open area. Installing the appropriate number of baffles achieves significant results, reducing echo and reverberation for a quieter, more tranquil atmosphere. Calculate the estimated quantity needed for your space and discover what results could be achieved using our reverberation time calculator.

Sunda Baffle has great acoustic properties and has up to Class A Sound Absorption rating depending on installation, spacing between the baffles and quantity. For a breakdown of acoustic performance tested against different frequencies, please see our datasheet in the downloads section on this page.

Sunda Baffle is manufactured in and shipped from the UK.

Sunda Baffles offer versatile solutions for spaces affected by reverberation and echo, particularly those with speech clarity and noise volume issues. Suited for various environments such as offices, meeting rooms, hotels, restaurants, village halls, schools, lecture theatres, music studios, and rehearsal spaces. These high-performing baffles effectively enhance room acoustics by addressing noise that typically rises to the ceiling, minimising reverberation and reflected sound. They are especially beneficial in areas with limited wall space.

Yes, the wire hanging kits provided with the Sunda Baffle are adjustable meaning that you can easily alter the height by simply pressing down on the clip that the wire feeds through. We recommend a minimum suspension drop of 150mm-200mm for optimal acoustic performance.

Yes, samples are available for Sunda Baffle. We can arrange for a product sample and a fabric swatch to be sent out to you on request to help you make your decision. Please contact us to arrange.

We hope that our product page and inspiration gallery will act as our brochure, and you can find the full product specification sheet on this page of which will provide the most important product information/data.

Your delivery will arrive fully packaged and protected on a specific vehicle for the size and weight of your delivery. The panels are generally hand balled off the vehicle unless a specific vehicle type has been requested. Should you have any specific requirements on site or at your premise it is important to notify us on order so that we can discuss suitable options that are available.

Sunda Baffle is manufactured to order and is on a short lead time that can be delivered between 3-7 working days dependent on the shipping type chosen as follows:

• Standard Delivery is 5-7 Working Days
• Premium Delivery is 3-5 Working Days
